Portable PDA Android 5.1 handheld barcode scanner android pda barcode ccd scanner
Product Description
DE1500 is a embedded barcode scanner module with leading CCD image recognition technology and intelligent image recognition system.
It can scan universal 1D barcodes, support USB, TTL multiple interfaces, read the paper, goods, screens, other media barcodes.
Easily embedded in a variety of OEM products handheld, portable, fixed and barcode collector, etc.
Features
☆ Mini size, cost-effective,widely used in PDA, mobile payment machines.
☆ Read all mainstream 1D barcodes in the market easily.
☆ High-performance processor, fast decoding. (3mil)
☆ Simple configuration, support upgrade online.
☆ Interface: USB, TTL, PS2
☆ Support multiple systems and languages, secondary development.
Application
▅ Lockers ▅ Mobile coupons, tickets
▅ Medical research ▅ Mobile payment barcode scanning
▅ Lottery machines ▅ Self-service terminals
▅ Queuing calling equipment ▅ Self-service vending machines
▅ Microcontroller development
Parameter
| Scan Type | Linear CCD |
| Light Source | Visible red light, 625±10nm |
| CPU | 32-bit |
| Resolution | 1500 |
| Reading precision | ≥4mil/0.1mm(PCS90%,Code 39) |
| Decoding speed | 300times/s |
| Depth of field | 60mm-500mm |
| Scan Mode | Manual ,Continuous |
| Scan angle | Test Conditions:CODE39,10mil/0.25mm,PCS90% |
| Pitch:±50° | |
| Roll: ±30° | |
| Skew: ±50° | |
| Print Contrast Signal | ≥25% |
| Ambient Light | Dark environment, indoor natural light |
| Symbologies | UPC-A,UPC-E,EAN-8,EAN-13,ISSN,ISBN,Code 128, GS1-128,ISBT 128, Code 39,Code 93,Code 11, Interleaved 2 of 5,Matrix 2 of 5,Industrial 2 of 5,Standard 2 of 5(IATA),Codabar(NW-7),Plessey,MSI Plessey,RSS,China Post,etc. |
| Weight | <6g |
| Dimension | (L)28mm * (W)22.5mm *(H)12.3mm |
| Communication Mode | FFC 12PIN Pitch 0.5 |
| Interface Type | USB,TTL |
| Power Supply | DC 3.3V@50mA(work) |
| Operating temperature | -20℃ to 50℃ |
| Storage temperature | -40℃ to 70℃ |
| Humidity | 5% to 95%(non-condensing) |
| Drop Height | 1.2m |
| Temp. Test | 30 minutes for high Temp., 30 minutes for low Temp., |
| High Temp. | 60℃ |
| Low Temp. | -20℃ |
| Transport vibration Test | 10H@125RPM |
Dimension
