Portable Field Calibration Device Single Phase Program Control Testing Source
Brand Name:GDZX
Model Number:ZX-1030
Minimum Order Quantity:1set
Payment Terms:L/C, D/A, D/P, D/P, T/T, Western Union, MoneyGram
Place of Origin:China
Price:4500USD/PCS
Contact Now
Add to Cart
Verified Supplier
Location:
Wuhan Hubei China
Address:
No.1 Fenghuangyuan Second Road, Jiangxia District, Wuhan City, Hubei Province, China
Supplier`s last login times:
within 1 hours
Product Details
Company Profile
Product Details
Class 0.05 Single Phase Program Control Testing Source
Introduction
This device adopts programmable FPGA, high speed high precision D/A converter, DDS technology, can regulate frequency, amplitude, phase signal source, and amplify signal power. It’s with high precision standards of voltage, current, power, electric energy inside, by analog closed loop feedback and digital PID control it can output voltage, current, frequency, phase, and trace the set parameters automatically over a long period of time. It is combination of standard power frequency indicating meter and energy meter, can be used to calibrate a lot kinds of electrical instruments. And It can connect with PC to realize automatic calibration and total management of testing data.
Features
1.Simplest structure but most reliable
2.High fidelity output signal and shock-proof ability by using high precision high power operational amplifier
3.dual output protection, built in U I F θ energy standard and PID control output, capable of long-term stable running
5.Color LCD display, easy to operate
6.With aluminum alloy carrying box, which look nice, weight less than 12 KG
Technical indicators
Power Frequency output voltage | output range | 0V ~ 720V, rated voltage range 25V,50V,100V,200V,400V,600V |
| Regulation range | 0~120% , Regulation fineness 5×10-5 | |
| Rated range error | class 0.1:≤±0.06%(Rd)±0.04%(FR) , class 0.5: ≤±0.03% (Rd)±0.02%(FR) | |
| output power | full range 100%, ≥20VA | |
Power Frequency output current | output range | 0A ~ 24A |
| Current ratings | 0.1A,0.5A,1A,5A,10A,20A | |
| Rated range error | class 0.1:≤±0.06%(Rd)±0.04%(FG) , class 0.05:≤±0.03% (Rd)±0.02%(FR) | |
| output power | 1~20A ≥20VA | |
| Output Frequency | range 45Hz ~ 65Hz, Resolution 0.001Hz error 0.01Hz | |
| Output phase position | 0.00 °- 359.99 °, error 0.1° | |
| Output harmonics | Harmonic 2~32 amplitude 0~20%, step 0.010·N(N is harmonic order#) | |
| Output wave form distortion | AC voltage current ≤0.3% | |
| Power frequency output power | range | rated voltage and rated current in any combination |
| Rated range error | class 0.1:≤±0.06%(Rd)±0.04%(fr) , class0.05:(≤±0.03% (Rd)±0.02%(fr) | |
| Remark | Reactive power accuracy will be one level lower | |
| Energy meter test | integrated error 0.1/ 0.05% FS (impulse output≤90kHz,3P ratings=60kHz) | |
| Others | Work power supply | single phase 220V±10%,50Hz±5% |
| Work environment | temperature 20℃±10℃, relative humidity ≤85%RH | |
| Size and weight | 460×480×200mm / 18kg | |
