TL632D MEMS Gyroscope Sensor Shock Resistance 20°/h Time Drift Gyro sensor
Product Description:
The MEMS Gyro Sensor has a time drift of 20°/h, which means that the output signal from the sensor will have a time-dependent error of 20° per hour. This specification is important for applications that require long-term stability and accuracy.
The MEMS Gyroscope Sensor is also designed to withstand high impact and shock. It can withstand an impact of 200g Pk, 2ms, ½sine, making it ideal for applications that involve high acceleration and vibration. The anti-vibration rating of the sensor is 10grms, 10～1000Hz, which means that it can withstand vibration and mechanical shock without affecting its performance.
The output configuration of the sensor is a MEMS DIGITAL TYPE GYROSCOPE, which means that it provides a digital output signal that is easy to process and integrate into various applications. The resolution of the sensor is 0.1°/s, which means that it can detect even the smallest changes in angular velocity. This high resolution makes it suitable for applications that require high precision and accuracy.
Overall, the MEMS Gyroscope Sensor is a state-of-the-art sensor that provides accurate and reliable measurements of angular velocity and orientation. It is a MEMS Three-Axis Gyroscope Sensor that can withstand high impact and shock, and has an anti-vibration rating of 10grms, 10～1000Hz. Its output configuration is a MEMS DIGITAL TYPE GYROSCOPE, and it has a resolution of 0.1°/s, making it a perfect fit for various applications such as aerospace, industrial, automotive, and consumer electronics.
Features:
★ High performance drift stability
★ Low noise
★ Compact & light design
★ Long life,strong stability
★ Cost-effective
★ Excellent vibration performance
★ All solid state
★ Light weight
★ RS232/RS485 output optional
★ Wide temperature range
★ DC9～36V power supply
★ Temperature drift< ±0.1°/sec/℃
Technical Parameters:
| TL632D | PARAMETERS | ||
| Measure range | ±50° | ±150° | ±300° |
| Measure axis | X,Y,Z(optional) | X,Y,Z(optional) | X,Y,Z(optional) |
| Bandwidth | >2000Hz | >2000Hz | >2000Hz |
| Resolution | 0.1°/s | 0.1°/s | 0.2°/s |
| Nonlinear | 0.1% of FS | 0.1% of FS | 0.1% of FS |
| Temperature drift | < ±0.1°/sec,/℃ | < ±0.1°/sec,/℃ | < ±0.1°/sec,/℃ |
| Start time | 5ms | 5ms | 5ms |
| Input voltage | +9～36V | +9～36V | +9～36V |
| Current | 60mA | 60mA | 60mA |
| Working temperature | -40℃ ~+85℃ | -40℃ ~+85℃ | -40℃ ~+85℃ |
| Store temperature | -40℃ ~+85℃ | -40℃ ~+85℃ | -40℃ ~+85℃ |
| Time Drift | 20°/h | ||
| Shock | 5g~10g | ||
| Impact | 200g pk,2ms,½sine | ||
| Working life | 10 years | ||
| Output rate | 5Hz,15Hz,35Hz,50Hz can be set | ||
| Output signal | RS232/RS485/RS422/TTL | ||
| MTBF | ≥98000 hours/times | ||
| Insulation resistance | ≥100M | ||
| Shockproof | 100g@11ms,3 Axial Direction (Half Sinusoid) | ||
| Anti-vibration | 10grms,10～1000Hz | ||
| Protection class | IP67 | ||
| Connector | 5 pins air-plug, matched with 1M cable | ||
| Weight | ＜180g(without cable) | ||
Applications:
★ Navigation
★ Robot
★ Car navigation
★ 3D virtual reality
★ Platform stability
★ Auto safety system
★ Remote control helicopters
★ Equipments
★ GPS combination
★ Camera stability
★ Turck-mounted satellite antenna equipment
★ Industrial control
★ Ships electronic needle error compensation on inclined(angle rate)induction equipment
