Product advantage of Core Builder Machine :

The core builder machine works smoothly, easy to operate, fast assembly, low energy consumption and no noise, accurate assembly size, uniform distribution, core forming neat and beautiful, easy to braze forming.

Procedure of producing radiator:

Prepare the radiator component, assemble the core, brazing, assemble the plastic tank,then finish assembling the whole radiator.

This core builder machine can assemble the head plate, fin, side plate, and other workpiece one-time assembly into the radiator core body.

Product parameters of Core Builder Machine:

Product features of Core Builder Machine :

The whole equipment adopts mechanical and electrical combination, PLC control, pneumatic components with mechanical device execution structure, with manual operation (tube, tape, head plate), automatic patting, clamping, assembly and other steps to complete the core assembly.

The equipment is easy to operate and can be set two operation modes: automatic operation and manual operation. The automatic operation mode is one-button operation, which is used for normal radiator or condenser core assembly production.

Manual operation mode is used for device mechanism adjustment

Product structure of Core Builder Machine:

The equipment is divided into frame and table, front and rear pressing adjustment mechanism, left and right assembly mechanism, comb mechanism, left head plate installation platform, right head plate installation platform, electrical control system.

Other machines for producing radiator:

Besides the core assembly machine, there are fin making machine, radiator clinching machine, brazing furnace, these are the basic equipment for producing the radiator,When all this equipment is equipped, it can build up a machine factory.

We can supply all these machines and aluminium components so that you can organize the production more smooth.

Below are some pictures of other machine for producing radiator:

Fin making machine

Radiator making machine

Brazing furnace
